Portable Conductivity Meter
HydroMetric portable conductivity meter is designed for professional field measurement of conductivity in water-quality surveys, treatment systems and process-water applications. The handheld platform automatically identifies the connected sensor and supports on-site parameter setting and calibration.
Technical Specifications
| Measurement principle | Conductivity cell method |
|---|---|
| Conductivity range | 1 µS/cm–2000 µS/cm (K=1); 100 µS/cm–100 mS/cm (K=10.0) |
| Resolution | 0.1 µS/cm to 0.01 mS/cm, depending on range |
| Accuracy | ±1% or 1 µS/cm, whichever is greater |
| Display | 3.5-inch color display with adjustable backlight |
| Data storage | More than 100,000 records |
| Power | Built-in rechargeable battery; USB charging |
| Mainframe material | ABS + PC |
| Protection | Handheld mainframe IP67; sensor IP68/NEMA 6P |
| Operating temperature | 0–50°C, non-freezing |
| Storage temperature | -15–60°C |
| Mainframe size / weight | 203 × 100 × 43 mm / 0.5 kg |
| Sensor cable | 3 m standard; extension available |
Field Applications
Suitable for portable conductivity testing in wastewater treatment, surface water, aquaculture, industrial and agricultural water supply and drainage, domestic water, boiler-water checks, swimming pools and research projects. Conductivity measurements can also support salinity and TDS assessment where the project configuration requires these derived parameters.
Operation & Integration
The ergonomic handheld host is intended for wet field environments. USB supports battery charging and data export, while automatic sensor identification simplifies field setup. For recurring monitoring programs, record the required conductivity range, expected salinity, water temperature and cable reach before selecting the conductivity-cell configuration.
Selection & RFQ Guidance
For quotation, specify the water type, expected conductivity range, whether salinity/TDS reporting is required, operating temperature, preferred cable length, sampling environment and quantity. HydroMetric can then match the appropriate conductivity-cell range and field accessories to the application.
Send the water type, expected conductivity range, salinity/TDS requirement, temperature, cable length and project quantity to sales@waterqualityanalyzer.com.
