Multiparameter Water Quality Controller
Industrial multiparameter controller for integrating multiple digital water quality sensors, local display, analog outputs, relays and remote communications in one panel.
Technical Specifications
| Sensor capacity | Up to 7 sensors |
|---|---|
| Display | 7-inch touchscreen |
| Power | AC 100–240 VAC (50/60 Hz) or DC 9–36 VDC |
| Analog outputs | 5 × 4–20 mA, programmable by parameter |
| Relays | 3 programmable relays |
| Communication | Modbus RS485 |
| Protection | IP65 / NEMA4X |
| Operating temperature | -15 to 60°C |
| Dimensions | 260 × 200 × 132 mm |
| Weight | Approx. 2.0 kg |
Supported Parameters
Compatible applications include pH, ORP, conductivity, dissolved oxygen, turbidity, suspended solids, chlorophyll, blue-green algae, UV COD, nitrate, ammonia, transparency, residual chlorine and other supported water-quality sensors.
Applications
Water treatment plants, wastewater systems, industrial process water, aquaculture and integrated online monitoring panels.
Request a Quote
Send your sensor list, signal requirements and enclosure/application conditions to sales@waterqualityanalyzer.com.
